SQT-112-01-F-D Cost Effective Rugged PCB Sockets, 2.00mm pitch

The SQT series offers cost-effective PCB sockets for through-hole termination. Available from single row up to 6 rows, this flexible range of sockets uses the proven Tiger Buy™ contact.

Download Product Specs

Features

Application: One to six rows with 50 pins per row for 300 I/Os
Contact System: Tiger Buy™
Orientation: Vertical, right-angle
Pitch: 2.00 mm (.0787")

Special Features: FleXYZ™ design allows design flexibility in all three axes
Termination: Through-hole
Automotive A-Series product available

2D view may not be representative of the configured product. Please see 3D preview or CAD download for actual representation.
Read our 3D Models Disclaimer.
Please confirm configuration with the Series Print before final design in.
For assistance with 3D Models, please contact [email protected].
For 3D Models suitable for EM Field Solvers, please contact Samtec’s Signal Integrity Group.

Get a Free Sample

Request Pricing Document

Get a Formal Quote

View Mating Products:
Mating Products

Stock
Ships Tomorrow: 30 pieces
Distributor Stock: 0 pieces

OEM Pricing
Breaks	1	50	100	500	1000	2000	5000	10000
Price	$3.713	$3.182	$2.704	$2.194	$1.945	$1.716	$1.258	$0.884

Please Login to see customer specific pricing. Or you may directly contact support.
You don’t have an account? Create one

Part Number	Ships Tomorrow	Packaging Type	Min	Mult	Difference
SQT-112-01-FM-D	200	Tube	1	23	Plating	Yes
SQT-112-01-LM-D	200	Tube	1	23	Plating	Yes

Packaging Notes
Packaging Type: Tube (23 parts per package)
