TLE-108-01-G-DV 2.00 mm Tiger Beam™ Cost-effective Single Beam Socket Strip

Features

Application: Standard and pass-through double row to 100 pins
Contact System: Tiger Beam™
Orientation: Vertical
Pitch: 2.00 mm (.0787")

Special Features: Cost-effective, reliable contact system
Termination: Surface mount
