TSW-110-07-L-S

.100" Terminal Strip

This through-hole .025” square post terminal strip features single, double and triple row options with straight or right-angle pins in a variety of post heights and body positions. This connector is an Extended Life Product™, passing 10 year Mixed Flowing Gas (MFG) and achieving high mating cycles (250 to 2,500).

Features
  • Pitch: .100" (2.54 mm)
  • Contact System: .025" (0.635 mm) square post
  • Orientation: Vertical, right-angle
  • Termination: Through-hole
  • Application: Industry's largest variety of standard pin counts, terminal lengths and options
  • Special Features: Many options for optimizing cost and performance with platings and ruggedizing features
3D Models

Looking for a 3D model? Select your format and download your model.

Specs Kit

Secured form. No spam.

Available to Ship: 451 pieces

  Distributor Stock: 5595 pieces

 |  Large Volume Lead Time: 2 weeks

Buckets 1 2500 5000 25000 50000
Price $0.512 $0.424 $0.363 $0.308 $0.198

Packaging Notes: Packaging Type:

Please Login to see customer specific pricing. Or you may directly contact support.
